DC 12V 24V 110V 220V Solenoid Valve 1/4" 1/8" 2 Way Normally Closed Direct-Acting Pneumatic Valves For Water Air Gas Hot

Translation missing: en.product.trust_badge.loved_worldwide

Description

SPECIFICATIONS

Actuator Mode: With Manual And Instruction

Brand Name: NoEnName_Null

Certification: None

Choice: yes

Coil Power: :6.5W

Flow Rate: :0.23Cv (Fluid Flow)

Hign-concerned Chemical: None

Material: Alloy

Media: Other

Model Number: Solenoid Valve

NC or NO: Normally Closed

Origin: Mainland China

Port Size: 1/8'' 1/4'',1/4

Power: Manual

Power Source: DC

Pressure: Medium Pressure

Standard or Nonstandard: Standard

Structure: Gate

Temperature of Media: Other

semi_Choice: yes



DC 12V Solenoid Valve 1/4" 1/8" 2 Way Normally Closed Direct-acting Pneumatic Valves For Water Air Gas

Specifications
Model Number: 2V025-1/4-12VDC/ 2V025-1/8-12VDC
Valve Type: 2 Way Normally Closed (Valve opens with energized)
Port Size: 1/4" NPT Female Port, 1/8" NPT Female Port
Coil Voltage: DC12V
Service Media: Air, Gas, Liquid, Water
Operation Model: Direct Acting
Flow Model: Uni-Directional
Flow Rate: 0.23Cv (Fluid Flow)
Response Time: Less than 50 ms
Operating Pressure: 1.2Mpa(can be operated at 0 PSI (Vacuum))
Operating Temperature: -10 to 80 °C
Coil Power: 6.5W
Material:
Body Material: Aluminum
Seal Material: NBR (Buna N)
Armature Tube Material: Brass
Plunger & Spring Material: Stainless Steel
Package included
1 x  Solenoid Valve



DC 12V 24V 110V 220V Solenoid Valve 1/4" 1/8" 2 Way Normally Closed Direct-Acting Pneumatic Valves For Water Air Gas Hot

Translation missing: en.product.trust_badge.loved_worldwide
Product form

SPECIFICATIONSActuator Mode: With Manual And InstructionBrand Name: NoEnName_NullCertification: NoneChoice: yesCoil Power: :6.5WFlow Rate: :0.23Cv (Fluid Flow)Hign-concerned Chemical: NoneMaterial: AlloyMedia: OtherModel... Read more

$40.12 $30.99 Excl. VAT

    • 🔁 Satisfait ou remboursé – 14-day return guarantee
    • ✅ Paiement sécurisé – Secure payment
    • 🚚 Expédition rapide – Fast processing
    • Guaranteed secure & safe checkout.

      stripe
    • 💬 24/7 Support | Assistance 7j/7 : autoentreprise224@gmail.com

      Description

      SPECIFICATIONS

      Actuator Mode: With Manual And Instruction

      Brand Name: NoEnName_Null

      Certification: None

      Choice: yes

      Coil Power: :6.5W

      Flow Rate: :0.23Cv (Fluid Flow)

      Hign-concerned Chemical: None

      Material: Alloy

      Media: Other

      Model Number: Solenoid Valve

      NC or NO: Normally Closed

      Origin: Mainland China

      Port Size: 1/8'' 1/4'',1/4

      Power: Manual

      Power Source: DC

      Pressure: Medium Pressure

      Standard or Nonstandard: Standard

      Structure: Gate

      Temperature of Media: Other

      semi_Choice: yes



      DC 12V Solenoid Valve 1/4" 1/8" 2 Way Normally Closed Direct-acting Pneumatic Valves For Water Air Gas

      Specifications
      Model Number: 2V025-1/4-12VDC/ 2V025-1/8-12VDC
      Valve Type: 2 Way Normally Closed (Valve opens with energized)
      Port Size: 1/4" NPT Female Port, 1/8" NPT Female Port
      Coil Voltage: DC12V
      Service Media: Air, Gas, Liquid, Water
      Operation Model: Direct Acting
      Flow Model: Uni-Directional
      Flow Rate: 0.23Cv (Fluid Flow)
      Response Time: Less than 50 ms
      Operating Pressure: 1.2Mpa(can be operated at 0 PSI (Vacuum))
      Operating Temperature: -10 to 80 °C
      Coil Power: 6.5W
      Material:
      Body Material: Aluminum
      Seal Material: NBR (Buna N)
      Armature Tube Material: Brass
      Plunger & Spring Material: Stainless Steel
      Package included
      1 x  Solenoid Valve
